Visinova 4G Pet Collar Camera（APG-202）

Category

Item

Parameter

Basic Info

Product Name

Pet Camera

Model No.

CW-01

Mechanical Parameters

Dimension (without clip)

72.5 × 43.5 × 24.5mm

Weight

100g

Material

ABS + PC

IP Rating

IP67

Main Controller

Ingenic T32-ZL

Sensor

Starway SC235HAI

SIM Card

Single Nano SIM Card

Connectivity

4G / BT 5.4 / GPS + AGPS

RAM

512MB

ROM

Max. 128GB, supports Class 10 & above TF card

G-Sensor

Supports automatic screen rotation

Speaker

0.8W

Battery Capacity

2000mAh

Charging Time

1 hour

Standby Time

3-5 days

Rated Power

2.0W

Operating Temperature

-10°C ~ 60°C

4G Module

SIMCOM A7670E-MLXY (EU Version, with GPS)
PN: S2-10EEN

LTE-FDD: B1/B3/B5/B7/B8/B20/B28

SIMCOM A7670NA-MNXY (US Version, with GPS)
PN: S2-10EJF

LTE-FDD: B2/B4/B5/B12/B13/B66

SIMCOM A7670C-MNXY (CN Version, with GPS)
PN: S2-10EJE

LTE-FDD: B1/B3/B5/B8
LTE-TDD: B34/B38/B39/B40/B41

SIMCOM A7670G-MNXY (Global Version, with GPS)
PN: S2-10EER

LTE-TDD: B34/B38/B39/B40/B41
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66

Software Parameters

System

Linux / RTOS

APP

UBox Pro

Resolution

HD: 1920×1080 @ 30FPS
SD: 640×360 @ 15FPS

Camera Viewing Angle

120°

White LED Flash

Supported

File Format

MP4
